According to the different particle size distribution of the selected iron ore, it can be divided into: ore shaker (to solve the excess iron ore) fine sand shaker (to solve the iron ore) and mud shaker (to solve the iron ore). The key difference between several kinds of shakers depends on: the form of the bed surface, the stroke, the stroke, the tilt Angle of the bed surface (horizontal tilt), etc.
The shaker is mainly used for sorting tungsten, tin, tantalum, niobium, chromium and other non-ferrous plates, non-ferrous metals and their precious metal iron ore, and can also be used for sorting iron, manganese and other iron ore. Separation of metal materials The reasonable separation particle size distribution category of iron ore is. For sorting the following 1mm, very much the following fine raw materials, the shaking table is a very reasonable sorting machine equipment.
Second, the principle of shaking table
The bed surface is arranged along the vertical layout of the bed strip (alias multiple strip), the height to width ratio of the bed strip slowly reduces to the same side of the self-drive system end, and shrinks along this or two slash tips. All bed surfaces are supported or suspended by the sound card frame. The sound card frame is equipped with slope adjustment equipment.
Raw materials (pulp or dry material) are sent to the tank body, and water is discharged together to prepare pulp with a concentration of about 20-40%, which is automatically flowed into the surface of the bed. The ore particle group is loosened and stratified by water cleaning and bed surface vibration in bed groove. The next layer of ore particles after the layer is subjected to different size of water flow working pressure and bed sliding friction effect, and exercise along different directions. The top layer of light mineral particles is subjected to greater hydraulic power generation promotion, so there is more exercise along the horizontal tilt of the bed. So the bottom side across the inclined plane is called the tailing side. The heavy mineral particles located at the bottom of the bed are immediately directed by the differential fitness movement of the bed surface to the web end of the transmission system opposite the door, which is the concentrate end.
From the beginning of the feed tank, the ore particle group follows a straight line in a fan shape. The material is discharged along the edge of the bed, and the ore discharge line is very long, so the shaker can accurately produce a variety of substances with different qualities. In order to reduce the harm of mineral particle size distribution to the separator, the raw materials entering the shaker must first carry out hydraulic power generation classification. The proportion of small is coarse grain, the proportion of large is fine grain.
Shaking table is the most common and highly efficient sorting machine for fine iron ore. Not only can the shaker smelter be used as a single smelter mode, but it is therefore synergistic with mining machinery and equipment such as jigging, flotation, magnetic separation and extraction smelter, spiral smelter, and transmission belt coal hopper. Look forward to about the introduction of shaker and shaker principle to help you!
