Excavator rollers: key components of the travel system

Full analysis of the supporting rollers of excavators: functions and inspection points

In the complex structure of the excavator, the supporting roller is a key component, and everyone is increasingly familiar with it. Today, let us explore the functions of the supporting rollers of the excavator and the inspection items that need to be carried out before use.
1. Functions of the supporting rollers of the excavator

The supporting roller plays an indispensable role in the operation of the excavator. Its main function is to smoothly transfer the weight of the locomotive group to the ground, and at the same time roll smoothly on the crawler to ensure that the excavator can move flexibly. In addition, in order to prevent the crawler from derailing during operation, the supporting roller also has the important role of preventing the crawler from moving horizontally relative to it.

However, the working environment of the supporting roller is extremely harsh, and it often runs in mud, water, ash and sand, and is subjected to strong impact. Under such conditions, the wheel rim is very easy to wear, which also puts higher requirements on the quality and performance of the supporting roller. The ideal supporting roller should have the characteristics of wear-resistant wheel rim, reliable bearing seal, and low rolling resistance to ensure the efficient operation of the excavator.

2. Inspection of the excavator supporting wheels of excavators

Before installing and using the excavator supporting wheels, strict inspection is the key to ensure their normal operation. The following are detailed inspection points:

Installation environment and cleaning: During the installation process, strict inspection must be carried out in accordance with the technical requirements of the parts. It is very important to keep the installation environment and the surface of the parts clean. Even if tiny dust particles enter the sealing end face of the sealing ring, it may damage the seal and cause oil leakage.

Inspection of sealing parts: If the sealing sleeve and sealing rubber ring are aged, deformed, scratched or cracked, they must be replaced with new ones. If the spring force is insufficient, it should be replaced in time. If the end face is uneven, it can be ground flat; if the pressure ring is warped, it needs to be repaired and leveled, and the sharp edges need to be removed.

Sealing ring processing: If the large and small sealing rings are not in close contact, they can be re-grinded to form a uniform and continuous grinding ring belt. During the operation, it should be noted that the ring end face is not allowed to hit and the spouse ring is not disrupted, and the thickness of the ring should be kept consistent, otherwise it needs to be replaced.

Rubber ring adjustment: If the thickness of the rubber ring is not enough, it is allowed to wrap asbestos rope to make it tighter than 0.15-0.20 kg per square centimeter.

Parts repair: The axle is bent, out of round or the neck is worn, as well as the wear of the supporting wheel hub and the seal housing matching belt. All need to be repaired.

Wear compensation and replacement: When the bearing and the sealing ring are worn on the plane, a 2-4 mm thick oil-resistant rubber ring can be used between the sealing sleeve and the end face of the hub according to the degree of wear. After installation, the sealing sleeve assembly should be able to rotate freely on the hub. In addition, a gasket with an outer diameter of 100 mm, an inner diameter of 85 mm, and a thickness of 1.5 mm can be used between the outer ring of the bearing and the support shoulder of the sealing housing to compensate for the bearing wear. When the height of the sealing sleeve is less than 32 mm and the width of the bearing is less than 41 mm, it should be replaced with a new one in time.

Paper pad inspection: The paper pad on the supporting wheel should be kept intact and of appropriate thickness to ensure its normal sealing and buffering effect.
Through an in-depth understanding of the functions of the excavator supporting wheels and strict inspections before use, we can better ensure the stable operation of the excavator and improve work efficiency. I hope the above content can help you in operating and maintaining the excavator.
